Elgin Model Reference, 16 Size

     Jeff Sexton
     jsexton@elgintime.com

Elgin 16 size movement models


16 Size, 1st Model
Three-Quarter Plate
Hunting and Open Face (Convertible), Lever Setting

Grades
47, 48, 49, 50, 72 and 93

16 Size, 2nd Model
Three-Quarter Plate, Three-Fingered Bridge
Hunting and Open Face (Convertible), Lever Setting

Grade 85, 86, 90 and 91
16 Size, 3rd Model
Three-Quarter Plate
Hunting, Lever Setting

Grades
1, 2, 3, 4, 92, 114, 127, 135, 136 and 137

16 Size, 4th Model
Three-Quarter Plate
Sweep Second, Hunting and Open Face (Convertible), Lever Setting

Grades
83, 84 and 89

16 Size, 5th Model
Three-Quarter Plate
Open Face, Pendant Setting

Grades
106, 107, 128, 138, 139, 140, 182 and 195

16 Size, 5th Model
Three-Quarter Plate
Open Face, Pendant Setting

This is the same as the above model, but with a slightly different plate layout.

Grades
105, 106, 107, 108, 128, 138, 139, 140, 182 and 195

16 Size, 6th Model
Three-Quarter Plate
Hunting, Pendent Setting

Grades
151, 152, 153, 154, 155, 185, 210, 212, 220, 257, 290, 292, 299, 312, 365 and 386

16 Size, 6th Model
Three-Quarter Plate, Three-Fingered Bridge
Hunting, Pendent Setting

This is the same as the above model, but in a bridged train variation.

Grades
156, 241, 242, 243, 247, 305, 337, 339, 381 and 397

16 Size, 7th Model
Three-Quarter Plate
Open Face, Pendent Setting

Grades
157, 158, 159, 160, 161, 186, 211, 213, 221, 258, 291, 293, 300, 313, 351, 366 and 387

16 Size, 7th Model
Three-Quarter Plate, Three-Fingered Bridge
Open Face, Pendent Setting

This is the same as the above model, but in a bridged train variation.

Grades
162, 244, 246, 248, 306, 338, 340, 382 and 398


16 Size, 8th Model
Three-Quarter Plate, Three-Fingered Bridge
Hunting, Lever Setting

Grade
341

16 Size, 9th Model
Three-Quarter Plate, Three-Fingered Bridge
Open Face, Lever Setting

Grades
270, 280 and 342

16 Size, 13th Model
Three-Quarter Plate
Open Face, Lever Setting

Grades
350, 360, and 361

16 Size, 14th Model
Three-Quarter Plate
Hunting, Lever Setting
Motor Barrel

Grades
371 and 373

16 Size, 15th Model
Three-Quarter Plate
Open Face, Lever Setting
Motor Barrel

Grades
370, 372, 374, 375, 376, 378 and 391

16 Size, 17th Model
Three-Quarter Plate
Open Face, Lever Setting
Motor Barrel

Grades
401 and 402

16 Size, 19th Model
Three-Quarter Plate
Hunting, Lever Setting with Winding Indicator
Motor Barrel

Grades
None known designated
